Formula1 racing is the pinnacle of automotive racing technology where performance and technologies employed challenge the very laws of physics. Inspired by full-scale Formula1 race cars, XRAY presents the all-new X1 based on XRAY’s European Championship-winning X12 pancar. Sharing many high-performance parts with its smaller cousin, the X1 has incorporated all of the finest details to achieve a state of race car perfection.
XRAY focused its efforts on refining all of the already well-thought-out parts and assemblies to make the new X1 easy to drive, work on, and adjust. Designed in virtual reality using the world's most sophisticated CAD technology, and manufactured using the world's best machining and molding machinery in-house, the X1 has attained a level of top perfection that is second to none.
All parts are purpose-designed and manufactured by XRAY from premium materials including legendary Hudy Spring Steel™, premium Swiss 7075 T6 aluminum, high-grade custom-formulated graphite material, and our own blends of composite materials. Everything on the X1 is premium with maximum attention to detail, so all parts fit and work perfectly together.
Elegant in its simplicity and effectiveness, the X1 is set to
become the new standard in 1/10 Formula racing.
XRAY focused its efforts on refining all of the already well-thought-out parts and assemblies to make the new X1 easy to drive, work on, and adjust. Designed in virtual reality using the world's most sophisticated CAD technology, and manufactured using the world's best machining and molding machinery in-house, the X1 has attained a level of top perfection that is second to none.
All parts are purpose-designed and manufactured by XRAY from premium materials including legendary Hudy Spring Steel™, premium Swiss 7075 T6 aluminum, high-grade custom-formulated graphite material, and our own blends of composite materials. Everything on the X1 is premium with maximum attention to detail, so all parts fit and work perfectly together.
Elegant in its simplicity and effectiveness, the X1 is set to
become the new standard in 1/10 Formula racing.
XRAY X1 Platform.
Legendary XRAY premium design, workmanship & material quality, and unmatched attention to detail result in a state of perfection achieved by well thought-out refinements to create a car that is easy to drive, work on, and adjust. From unique HUDY Spring Steel™, through the world’s strongest Swiss 7075 T6 aluminum, along with XRAY’s own secret composite materials, to premium high-grade graphite materials… everything is exclusive and premium on the X1. Using premium European exclusive materials crafted by XRAY’s engineering artists using state-of-the-art German, Italian, and Swiss CNC machines, the X1 is born from the finest the world has to offer.
ETS Champion.
No other 1/10 Formula car had such an incredibly outstanding prototype debut than the new X1. Jan Ratheisky and Francesco Martini debuted the very first X1 prototype at its first official race at no less than the world's most competitive race series – the ETS series. They went on to have the most successful prototype debut ever by claiming an overall ETS season formula champion title by Jan Ratheisky, and third overall position by Francesco Martini. Now the rest of the world can enjoy and race the same ETS Championship-winning Formula car; trialed by fire and successfully proven itself in the most competitive racing series in the world.
Development Team.
“The X1 project was very dear to the hearts of the Development Team, having been a long-awaited and long-coveted project whose time had finally come. Responsibility was split between three key people: myself, Francesco Martini, and Jan Ratheisky.Franci has been very instrumental in the R&D of previous cars – especially the T4 – and on the X1 his creativity and attention to detail really shone brightly. His passion for F1 drove him and the project to new heights and it was an easy decision to have him take over this project. Working in his native Italy, Franci was responsible for inputs to design, and testing the first prototypes. Thanks to the marvel of near-instantaneous communication and collaboration, we stayed in daily contact. Ideas and changes were integrated into 3D models, and after more collaboration there were further evolutions of design. Rapid prototypes were sent to Franci for testing and data collection, which resulted in even further progress.
We had the good fortune to have Jan Ratheisky join our team, and he was very excited to have the opportunity to be part of the R&D team and test our X1 creation. Jan is one of the world’s best formula racers and ETS formula champion, so our project was in very capable hands; if Jan liked it and was faster because of it, we knew we were doing things right. Working with Jan was very positive and effective, and immediately our progress started to take giant leaps forward. The pace was fast and furious, sometimes exhausting but always thrilling.
We couldn’t have asked for a better team to bring the X1 to life. I am very proud of both Franci & Jan for their contributions to the X1 project, so I give them a very big and very heartfelt “Thank you!” Now it is time to unveil the X1 to the world… get ready to be amazed and thrilled!”
Martin Hudy
XRAY X1 Designer
We couldn’t have asked for a better team to bring the X1 to life. I am very proud of both Franci & Jan for their contributions to the X1 project, so I give them a very big and very heartfelt “Thank you!” Now it is time to unveil the X1 to the world… get ready to be amazed and thrilled!”
Martin Hudy
XRAY X1 Designer
Exclusive photos from Making of X1.
Chassis.
Chassis design, layout, and flex have significant influence on handling of the X1. The final chassis design offers optimal stiffness for excellent handling, while still being flexible enough to generate maximum traction. The super-narrow chassis front allows for maximum traction while keeping sufficient steering and cornering speed. The chassis has ideal torsional stability, while at the same time eliminating the “scrub effect” in high-speed corners.CNC-machined from custom-manufactured 2.5mm high-grade graphite material with a specially-designed compound for carpet racing and asphalt racing, the X1 handles ideally on either indoor or outdoor tracks, on either carpet or asphalt.
The chassis is the central backbone of the car. All main components attach to the rear pod suspension, which is directly connected via chassis links.
The chassis is the central backbone of the car. All main components attach to the rear pod suspension, which is directly connected via chassis links.
Weight Balance.
The layout of the electronics and position of individual sections of the car were designed with optimum weight distribution and balance in mind. During the design and prototyping phase, several different layouts were tested, and an extensive amount of data was collected, compared, and evaluated by the Factory Team before the final design was chosen.The steering servo is located in a lay-down position for lowest CG at the chassis center, and the layout of the chassis allows the batteries to be placed either inline or cross-chassis. Depending on battery configuration, the ESC and receiver can be placed in various positions to give ideal weight transfer and balance.
Battery Placement.
Battery placement on the chassis has a significant influence on weight balance. Battery placement can be quickly changed from inline to cross-chassis, to offer ideal weight balance depending on various track conditions. Composite battery backstops are included to eliminate battery movement.Rear Pod.
The narrow chassis layout with super-narrow rear pod design allows the composite rear pod links to be placed closer to the chassis centerline, which improves steering response and gives optimal side-to-side weight transition.The compact and ultra-lightweight rear pod is constructed from high-strength aluminum bulkheads, graphite brace (which includes multiple wing height mounting positions), and thin but strong high-grade graphite plates.
The smart pod design accommodates all motors, and allows for super-easy motor access. Eccentric composite bushings are included for ultra-fine rear ride height adjustment.
Rear Link Brace.
The rear graphite brace holds the battery in place and is the mounting base for the side shock. As well, the side springs are positioned on the brace (instead of side links) for better and more consistent damping. Aluminum stands make for a strong design that is durable and resistant to tweak.Centralized Shock Mount.
The front center shock mount is positioned in the absolute chassis center for perfect side-to-side weight transfer. The rigid centrally-mounted shock mount (with strong aluminum stands) prevents tweak and significantly improves side-to-side stability.
Pod Upper Plate.
The rear pod upper plate is the base for the central shock, the platform for the side shock, and it connects the front chassis assembly with the rear pod. Machined from premium high-grade graphite, the pod plate is very strong and gives rigidity to the entire rear assembly.
Shock Absorber.
The X1 features a well-proven XRAY shock from the touring car platform. The unique XRAY aluminum shock absorber has interchangeable internal parts, with fixed 1-piece precision pistons which are available with 3 different-diameter holes for damping adjustment: 1.0, 1.1, and 1.2mm with 2 and 3 holes. No matter what you choose, all pistons are ultra-true and round due to a very special mould design, resulting in ultra-free movement of the piston inside the shock body.
The aluminum shock body is precision CNC-machined on the world’s most precise German long-turn CNC machine and every piece is robotically-inspected and measured to ensure maximum precision and tolerance. This is especially important with the inner diameter of the shock body to ensure that each one has an identical inner diameter to guarantee ultra-free shock piston movement.
The aluminum shock body is machined from exclusive Swiss 7075 T6 aluminum for maximum strength and rigidity. The shock body is black hardcoated using XRAY’s own fully robotic color-coating line with purpose-mixed color fluids, ensuring that a very even layer of color coating is applied to each shock body. After the coating process, every shock body is manually checked with high-precision calipers to ensure that the inner diameter of each shock body is exactly within very tight tolerances.
The shock cartridge has been designed for self-centering shim to hold silicone O-rings, guaranteeing perfect alignment in the shock body. A finely-threaded aluminum shock lower cap secures the silicone O-rings and shims in the shock body.
Finely-threaded spring preload collar is used for quick and easy adjustment.
Finely-threaded spring preload collar is used for quick and easy adjustment.
The upper aluminum cap features a small vent hole which makes shock assembly very predictable and easy, since excess shock oil will escape through this vent hole ensuring that the proper amount of the oil remains inside the shock assembly.
A super-soft silicone membrane – supported by a miniature foam pad (inserted inside the membrane) – provides proper damping characteristics.
A super-soft silicone membrane – supported by a miniature foam pad (inserted inside the membrane) – provides proper damping characteristics.
Shock Spring.
To make the car more stable and easier to drive under various track conditions, the 2.2 linear spring was chosen as the basic setting to provide the best balance between traction, stability, and steering response.A complete range of optional springs is available for further fine adjustment.
Side Shock.
The chassis is supported by an ultra-precise micro-size side shock which is machined from premium Swiss 7075 T6 aluminum. The shock absorber is silicone oil filled to ensure constant and ultra-smooth damping. The side shock delivers maximum traction, especially in low-to-medium traction conditions.
Side Springs.
Side springs are placed directly on the chassis for smooth and precise movement. Straight side springs have more consistent and smoother compression for smoother out-of corner exiting, and reduction of traction rolling. Optional side springs are available.
Pivot Brace.
The transition of the rear pod works via the pivot brace, which features an ultra-small and lightweight pivot ball that allows for greater movement of the pivot brace. The pivot ball has an internal thread.
Servo Saver.
The tiny yet robust servo saver protects the servo from impact damage. The 4-spring servo saver gives precise steering, making the car easier to drive while giving consistent handling.
High-Grade Graphite Parts.
All graphite parts are CNC-machined from custom-manufactured 2.5mm high-grade graphite material with a specially-designed compound for carpet racing and asphalt racing, the X1 handles ideally on either indoor or outdoor tracks, on either carpet or asphalt.
Premium Composite Parts.
All composite parts are manufactured by XRAY using premium self-developed composite mixtures which guarantee sufficient flex of the suspension parts, while being hard enough to withstand hard impacts.
Front Suspension.
Strong, simple, fully adjustable, yet smart and ultra-efficient front suspension consists of high-grade graphite lower & upper suspension arms, arm mount plate, and aluminum stands.Steering blocks are made from strong, lightweight, self-developed composite material. Tiny yet strong composite pivot balls ensure smooth, bind-free operation.
Fast & easy adjustment of front caster, track-width, roll center, camber, and ride height are made via included shims and eccentric bushings.
Caster is adjusted via eccentric bushings, offering 3°, 6°, 9°, and 12° settings.
Camber is adjusted via eccentric bushing, offering 1.0°, 1.5°, 2.0°, and 2.5° settings.
Front Track-Width Adjustment.
The front track-width can be easily adjusted via the shims inserted between the wheel and the front suspension block. Shims for track-width adjustment are included.
Camber Adjustment.
Front camber is easily adjusted via front upper arm eccentric bushings. The kit includes two eccentric bushings; by changing the orientation of the bushings, camber settings of 1.0°, 1.5°, 2.0°, and 2.5° can be achieved.
Caster Adjustment.
Caster is easily adjusted via front upper plate eccentric bushings. The kit includes two eccentric bushings; by changing the orientations of the bushings, caster settings of 3°, 6°, 9°, and 12° can be achieved.
Roll Center Adjustment.
Front upper & lower roll centers are easily adjusted via included shims. Changing the lower roll center position, the ride height of the car is adjusted at the same time.Front upper arm roll center is adjusted by inserting shims under the arm mount plate alu stands.
Lower roll center position/ride height is adjusted via shims inserted under the front lower suspension arm alu stands.
Ride height can be also adjusted via shims above & below the steering block on the kingpin axle.
Steering.
The chassis features pre-drilled holes to accommodate either a micro or mid-size steering servo.
The servo is positioned in the chassis center for perfect steering characteristics, and connects to the suspension blocks via the centrally-positioned servo arm with adjustable Ackermann. Aluminum servo stands allow flat mounting of the servo to the chassis to give the lowest possible CG.
Back Stop.
The steering backstops mounted on the lower arms allow for the adjustment of maximum steering angle. The advantage of the backstops is that both steering sides can be adjusted to the same angle. Maximum steering angle can be adjusted depending on traction, surface conditions, and tires: under high-traction conditions, the maximum steering angle can be decreased to make the car easier to drive and eliminating traction rolling, or the maximum steering angle can be increased for more cornering speed.
Steering Arm.
The steering arm includes two Ackermann positions; the inner position achieves maximum steering angle quicker so the car is more responsive, while the outer position makes the car easier to handle in corners.
Bump steer shim thickness can be changed depending on track conditions. 4mm shims are included for the steering arm to make the car easier to drive under high-traction conditions.
Kingpin.
The front suspension assembly features composite pivot balls that allow the front suspension to work very smoothly. Super-smooth, hardened steel kingpins provide the foundation for the front suspension.
Steering Blocks.
Tiny, tough steering blocks each feature two Ackermann positions. The super-precise inner hole for the kingpin steel pin ensures a wobble-free assembly.
Wheel Axles.
Ultra-precise wheel axles are CNC-machined from premium HUDY Spring Steel™ and are additionally hardened and hand-ground for precision fitment.
Rear Suspension.
The rear suspension features a conventional rear pod that is adjustable via pivot-ball links, providing extremely easy assembly and tuning while being very effective and giving the highest competitive performance.
Alu Bulkheads.
Rear pod bulkheads are CNC-machined from premium extra-hard Swiss 7075 T6 aluminum, additionally black coated for long life and stylish look. The bulkheads are strategically machined to reduce weight to minimum while retaining strength.Motor Access.
The rear pod accommodates all motors. The open-top design of the rear pod left-side bulkhead provides super-easy motor access.
Rear Axle.
The ultra-strong lightweight steel axle is used to provide maximum reliability even in serious crashes. The rear axle is hollow for lightest weight while still ensuring maximum strength. The rear differential features high-grade precision carbide balls for spur gear, hardened & precision-ground D-shaped steel shims, and premium carbide axial thrust-bearing.Spur Gear.
The precision-molded spur gear is made from XRAY's exclusive composite material, ensuring true running, super-quiet operation, and robustness for use with powerful motors. A range of optional spur gears is available for fine tuning.Alu Rear Hubs.
Aluminum rear hubs are machined from lightweight aircraft aluminum, specially lightened and black-coated for stylish looks. The rear left aluminum wheel hub features a center-balanced clamping mounting system, ensuring secure mounting while eliminating vibration and run-out.
Rear Ride Height.
Ride height is easily adjustable using included eccentric rear axle bushings, as well as adjustable shock preload for middle ride height adjustment.
Adjustable Turnbuckles.
Steering linkages consist from adjustable 3mm turnbuckles manufactured from lightweight Swiss 7075 T6 aluminum which are used to adjust front toe.
Ball-Bearings.
A full set 11 high-speed, blue-sealed, steel ball-bearings are used throughout the drivetrain and steering to ensure maximum efficiency. All bearings are degreased and oiled with AeroShell® Fluid 12 for maximum smoothness and long life.
Adjustable Body Posts.
Robust body posts have fully-adjustable body holders and are rear posts are mounted on the solid graphite platform on alu stands.
Front Spoiler.
The front spoiler consists of two parts: a composite bumper and a Lexan™ downforce spoiler.The composite front chassis bumper is very rigid yet flexible, and provides protection where the car needs it most… in the front corners of the chassis where damage may occur from impacts.
The lightweight Lexan™ front spoiler is mounted to the composite front bumper and provides the necessary aerodynamic characteristics. There are two types of spoilers included: low downforce & high downforce, and each are used in particular track conditions.
Rear Wing.
The efficient rear wing works in conjunction with the X1 racing body. The rear of the body has flow channels which direct air directly onto the wing to help generate rear traction and stabilize the car in chicanes.
The wing is assembled via the rear wing mount system which features a graphite mount and aluminum stands. Using optional alu shims between the wing and the alu stands, the position of the wing can be easily adjusted to various track conditions. The height of the rear wing can be adjusted by changing the mounting position on the graphite plate.
The wing is assembled via the rear wing mount system which features a graphite mount and aluminum stands. Using optional alu shims between the wing and the alu stands, the position of the wing can be easily adjusted to various track conditions. The height of the rear wing can be adjusted by changing the mounting position on the graphite plate.
X1 Body.
The high-performance, low-profile aerodynamic body was designed to perfectly fit the X1 and to work under most all track conditions while keeping the full-time F1 style and look. The front and rear of the body have been designed to provide downforce for maximum stability and direct airflow to the rear wing. The body sides as well as cockpit sides are as flat as possible to direct airflow around the body for maximum stability. The body is made from high-quality premium Lexan™ material. The integrated helmet ensures the body is legal for races where a pilot figure helmet is required without adding extra weight.XRAY Orange Color.
Most aluminum parts are orange anodized for a very distinctive XRAY design look. The combination of traditional XRAY’s orange and black coloring gives the car the perfect look and appeal.
Silicone Oils.
XRAY Premium Silicone Oils are manufactured in Europe by a specialized premium silicone oil manufacturer; these new oils were exclusively created for XRAY. Each batch of premium oil is laboratory tested and calibrated to ensure the highest possible consistency and quality batch-to-batch. Based on the industry-standard cSt rating, the new line of oils will be easy to identify, adjust, and feel.
When following any set-up sheets by XRAY or Team XRAY drivers, you can be sure that the oils you will get for your car will be exactly the same as those used by the factory racing team, thus ensuring very exacting set-ups and handling of the car.
When following any set-up sheets by XRAY or Team XRAY drivers, you can be sure that the oils you will get for your car will be exactly the same as those used by the factory racing team, thus ensuring very exacting set-ups and handling of the car.
Fully Adjustable.
Fully adjustable front camber, caster, track-width, front & rear ride height, central & side shock absorbers, central shock spring, pod damping, battery position, weight balance, differential, Ackermann, bump steer, front downforce spoiler and rear wing.Chassis Weight Balance Adjustment.
Chassis and rear pod features pre-drilled centerline holes for optimum weight balance adjustment using HUDY Balancing Tool #107880.
XRAY Instruction Manual.
XRAY Instruction Manuals have become the industry standard, and are simply the best manuals you will ever get with an RC model car. Whether you are a first-time builder or an experienced racer, all the instructions are straight-forward and easy to understand. The full-color instruction manual contains large 3D illustrations for easy comprehension.
XRAY VIP Customer Treatment.
Owning an XRAY model racing car is an experience on its own. Not only will you own the most premium luxury model racing car, but you will also become a member of the prestigious family of XRAY owners with superb support and service from the XRAY factory. The XRAY Web portal features up-to-date racing news and latest product developments. If you have any questions, problems, or comments, you can ask the XRAY Support Team or any XRAY Factory Team Driver on the XRAY Support Forum. You can even upload your own set-up sheets or download from the largest RC set-up database at the exclusive XRAY Virtual Set-up Sheet Database. And that is only the start of the VIP treatment you get by joining Team XRAY.General
XRAY 1/10 Formula race car with authentic 100% self-developed XRAY parts, designed and manufactured parts by XRAY in Europe
Legendary XRAY premium design, workmanship & material quality and unmatched attention to the finest details
Simple yet effective and proven design, well thought-out details, unmatched precision in all details
High-competition design with focus on ultra-low weight, resulting in super-lightweight construction
Optimized for indoor carpet racing as well as outdoor asphalt racing
Elegant in simplicity & effectiveness, the X1 is set to become the new standard in 1/10 Formula racing.
Chassis
CNC-machined from custom-manufactured 2.5mm high-grade graphite material with a specially-designed compound for carpet racing and asphalt racing.
Super-narrow chassis front allows for maximum traction while keeping sufficient steering and cornering speed.
Chassis design has optimal stiffness for excellent handling, flexibility for maximum traction, and ideal torsional stability.
Superb handling on either indoor or outdoor tracks, on carpet or asphalt.
Improved steering response and optimal side-to-side weight transition.
Rear graphite brace holds battery in place, and provides a solid mounting base for the side shock.
Battery placement can be quickly changed from inline to cross-chassis, to offer ideal weight balance depending on track conditions; composite battery backstops eliminate battery movement.
Laydown steering servo orientation for lowest CG at chassis center
Front center shock mount is positioned in the absolute chassis center for perfect side-to-side weight transfer.
Chassis and rear pod feature pre-drilled centerline holes for optimum weight balance adjustment using HUDY Balancing Tool #107880
Front Suspension:
Strong, simple, fully adjustable, yet smart and ultra-efficient front suspension
High-grade graphite lower & upper suspension arms and arm mount plate
Tiny, strong composite pivot balls for smooth, bind-free operation.
Adjustable front caster via eccentric bushings for front upper plate: 3°, 6°, 9°, and 12°
Adjustable front camber via eccentric bushings for front upper arms: 1.0°, 1.5°, 2.0°, and 2.5°
Adjustable front upper & lower roll centers via included shims
Adjustable front track-width adjustment via included wheel axle shims.
Steering:
Tiny, robust 4-spring servo saver protects the servo from impact damage. Provides precise steering and consistent handling, while making the car easier to drive.
Pre-drilled chassis holes to accommodate either a micro or mid-size steering servo.
Centralized servo position for perfect steering characteristics
Centrally-positioned servo saver arm with selectable Ackermann positions
Adjustable bumpsteer characteristics via included shims
Steering backstops mounted on lower arms allow adjustment of maximum steering angle
Super-tiny yet robust steering blocks with multiple Ackermann positions, and ultra-precise inner hole for kingpin ensures wobble-free assembly.
Super-smooth hardened steel kingpins
Adjustable, lightweight aluminum turnbuckles for front toe adjustment
Rear Pod:
Compact, ultra-lightweight rear pod design with composite rear pod links located closer to chassis centerline.
Narrow rear pod design gives improved steering response and optimal side-to-side weight transition.
CNC-machined pod bulkheads made from premium extra-hard Swiss 7075 T6 aluminum, additionally black coated for long life and stylish look
Rear pod upper plate made from strong graphite plate is the base for the central shock, the platform for the side shock, and it connects the front chassis assembly with the rear pod.
Rear graphite brace features multiple wing height mounting positions.
Smart pod design accommodates all motors, allows for super-easy motor access.
Pod pivot brace features an ultra-small and lightweight pivot ball for smooth movement.
Eccentric composite bushings are included for ultra-fine rear ride height adjustment.
Ultra-precise, micro-size side shock is machined from premium Swiss 7075 T6 aluminum, and is silicone oil filled to ensure constant and ultra-smooth damping.
Linear side springs for more consistent and smoother compression for smoother out-of corner exiting, and reduction of traction rolling.
Shock:
Well-proven XRAY racing shock from touring car platform.
Interchangeable internal parts, with fixed 1-piece precision pistons which are available with 3 different-diameter holes for damping adjustment: 1.0, 1.1, and 1.2mm with 2 and 3 holes.
CNC-machined Swiss 7075 T6 alu shock body, hard-anodized, with fine external threading for quick & easy shock spring preload adjustment
Super-soft silicone shock O-ring for smooth operation while preventing oil leakage
Ultra-finely finished hardened shock shaft
Self-centering shims hold the shock O-rings, for perfect alignment in the shock body.
Finely-threaded aluminum shock lower cap secures the silicone O-rings and shims in the shock body.
Super-soft silicone membrane, supported by a miniature foam pad, provides proper damping characteristics.
The 2.2 linear shock spring provides the best balance between traction, stability, and steering response; a complete range of optional springs is available for further fine adjustment.
Drivetrain
CNC-machined ultra-precise wheel axles made from premium HUDY Spring Steel™ are additionally hardened and hand-ground for precision fitment.
Ultra-strong lightweight hollow steel axle for maximum reliability and reduced rotational weight
Rear differential with high-grade precision carbide balls for spur gear, hardened & precision-ground D-shaped steel shims, and premium carbide axial thrust-bearing.
Precision-molded spur gear made from XRAY's exclusive composite material, ensures true running, super-quiet operation, and robustness for use with powerful motors.
CNC-machined rear hubs made from lightweight aircraft aluminum, specially lightened and black-coated for stylish looks
Rear left alu wheel hub features a center-balanced clamping mounting system, ensuring secure mounting while eliminating vibration and run-out.
Full set high-speed, blue-sealed, steel ball-bearings used throughout the drivetrain and steering to ensure maximum efficiency. All bearings are degreased and oiled with AeroShell® Fluid 12 for maximum smoothness and long life.
Easy rear track-width adjustment via included shims
Body & Aerodynamics:
Robust body posts mounted on the solid platform on alu stands, featuring fully-adjustable body holders.
Multi-part front spoiler consists of composite bumper and Lexan™ downforce spoiler.
Composite front chassis bumper is very rigid yet flexible to provide superior protection.
Lightweight Lexan™ front spoilers – choice of low or high downforce spoilers for difference track conditions.
High-efficiency, high-strength rear wing with adjustable mounting height position on pod rear graphite plate
High-performance, low-profile aerodynamic X1 body made from high-quality premium Lexan™ material for maximum versatility in most track conditions. Rear air channels direct airflow onto rear wing. Body sides as well as cockpit sides are as flat as possible to direct airflow around the body for maximum stability. On the rooftop, two flow channels are incorporated for proper air flow. An integrated helmet ensures the body is legal for races where a pilot figure helmet is required.
Assembly & Support:
Highest quality of all composite parts ensures super-precise fitment, easy assembly, and smooth operation of all parts
Premium 3D full-color Instruction Manual
Exclusive Virtual Online Set-up Sheet database with thousands of set-up sheets for race tracks around the world
Premium, unmatched XRAY online support
Adjustment Possibilities:
Front camber, caster, and toe
Front & rear track-width
Front, center, and rear ride height
Front springs
Fully-adjustable rear shock absorber
Side shock for lateral pod damping
Chassis tweak
Ackermann
Bump steer
Differential settings
Battery position
X1 Specs:
| Dimensions | |
|---|---|
| Class : | 1/10 formula |
| Width : | Adjustable 180mm front, 185mm rear (depends on tires used) |
| Lenght : | 410mm |
| Wheelbase : | 264mm |
| Weight : | 375g |
| Ready-to-run weight : | 985g (varies depending on equipment used) |
| Chassis | |
| Chassis : | 2.5mm carbon fiber, CNC machined |
| Body : | XRAY X1 1/10 formula type |
| Drivetrain | |
| Type : | 2WD direct drive to rear axle |
| Rear Axle : | Steel shaft with ball differential |
| Primary : | Spur/pinion |
| Bearings : | High-speed ball-bearings (11) |
| Suspension | |
| Front : | Spring-supported, kingpin-style front suspension with composite steering blocks and graphite upper & lower suspension arms |
| Rear : | Conventional rear pod, adjustable via pivot-ball links, controlled by side tubes |
| Rear Shock : | Central adjustable oil-filled shock absorber |
| Geometry | |
| Ride Height : | Adjustable front + rear |
| Camber : | Adjustable front |
| Front Caster : | 3–12° adjustable caster |
| Track-width : | Adjustable front + rear |
| Toe : | Adjustable front |
| Downstop : | Adjustable rear |
| Ackermann : | Adjustable with servo saver arm and steering block |
| Steering : | Direct linkage between steering arm and steering blocks |
| Balance : | Front/rear weight balance adjustable via battery position |
| Other | |
| Wheels : | Not included |
| Tires : | Not included |
| Instructions : | Full colour instruction manual |
| Set-up book : | 2-color Set-up Book (16 pages) – not included |
| Packaging : | Carton box with vinyl bags with parts |
| Additionally included : | Lexan Formula body & front wing, HUDY Diff Grease, Authentication Certificate, parts list & exploded view, shock oil |
| Not included : | Motor, batteries, speed controller, tires, body, steering servo, radio equipment |
X1 Gallery
XRAY X1 Exclusive Story
50,000원 이상 주문시 무료배송! (단, 50,000원 미만 주문시 배송료 3,000원이 추가됩니다.)
- RC용품 제조사 A/S규정안내
- 변속기,배터리,모터,수신기 킷트 등의 모든 RC용품은 제조사의 공장 출고시 불량을 제외한 어떠한 경우에도 제조사의 규정에 의해 일체 교환 및 무료 A/S는 불가합니다. (알씨마을의 규정에 의한 것이 아니니 이점 이용에 참고하시기 바랍니다.)
- 최초 불량이 아닌 사용중 파손시 고객님께서 직접 수리 및 부품교환을 하셔야 하나 수리가 어려울 경우 알씨마을로 문의 주시면 부품 + 공임(공임은 작업량에 따라 약 1만~5만원)으로 유료 A/S(수리)를 해드릴 수 있습니다.
- 제 1 조 알씨마을의 부담으로 재배송 또는 반품, 교환, 환불해 드리는 경우
- 1. 주문한 상품과 다른 상품을 배송한 경우
- 2. 주문한 상품의 수량과 수령한 상품 수량이 다를 경우
- 3. 상품의 파손 손실된 상품을 배송한 경우
- 4. 상품(택배)을 받지 못했을 경우
- 제 2조 고객께서 비용을 부담 하셔야 하는 경우
- 1. 고객님의 변심으로 반품, 교환을 원하는 경우(단, 개봉한 상품은 불가)
- 2. 주문시 배송지 주소를 잘못 기입하여 배송받지 못한 경우
- 3. 주문시 호환여부를 잘못 판단하여 사용할 수 없는 상품을 주문한 경우
- 4. 수령한 상품을 사용중에 부품이 파손된 경우
- 5. 수령한 상품을 사용중 초기셋팅값을 변경하여 시동 또는 작동이 되지 않을시 유선상 처리가 불가한 경우
- 제 3 조 기타 유의 사항 안내
- 1. 알씨마을 쇼핑몰의 상품상세정보는 실제 상품정보와 약간의 차이가 있을 수 있습니다.
- 2. 옵션 상품등 호환되는 상품 주문시 꼼꼼히 호환여부를 확인 후 주문하시기 바랍니다.
- 3. 파손된 상품 또는 불량에 대한 이의 제기는 택배수령후 3일 이내에 하셔야 합니다.
- 4. 개봉한 상품은 반품, 교환되지 않습니다.
- 5. 반품, 교환시 배송중 파손될 경우 그 손해는 고객님께서 부담하셔야 합니다.
- 6. 구매자의 사용 미숙으로 발생한 신체 또는 재산상의 손해에 대하여 일체 책임 지지 않습니다.
