ATK4895-K10 Thunder Tiger 4895-K10 Raptor G4.1 Nitro Flybarless 90 Size

This is the radio controlled, glow powered,
           Thunder Tiger Raptor 90G4.1 Flybarless Helicopter Kit.
                For Intermediate to Advanced RC Heli Pilots.

     **Additional Technical Info Will Be Added When It Becomes Available.**

FEATURES: Control System: 135/140° Collective Cyclic Pitch Mixing (ECCPM),
            +/-15° collective pitch range, adjustable Bell-Hiller mixing ratio
            can be set for F3C or 3D
          Main Frame: 0.08" (2mm) thick carbon side frames refined to allow use
            of the 115T main gear for use with the OS 105HZ engine
          Rotor Head: Full aluminum, with thicker grip plates for greater
            rigidity and better 3D performance, lengthened posts, reinforced
            bearing block with added crossmember
          Drive System: Torque tube for 100% power transfer and crisp tail
            rotor response
          Main Shaft: 15mm diameter hardened steel, hollow design
          Tail Boom: Carbon with carbon support and fin, one-piece metal
            bracket
          Tail Rotor System: All metal, heavy duty with rotor rod guide and
            heavy duty helical bevel tail gears, torque tube driven
          Tail Case: One-piece machined metal
          Tail Blades: Carbon, 4.1" (105mm) in length
          Battery Tray: Quick change bottom access
          Canopy: FRP, preprinted yellow in color
          Main Gear: Lightweight and vented heavy duty 17mm helical
          Fuel Tank: Main 22oz (650cc), Header Tank 2.02oz (60cc)
          Landing Gear: Nylon with aluminum skids

INCLUDES: Flybarless Raptor 90G4.1 Helicopter Kit with FRP Canopy, Main &
            Header Tanks, Tail Boom and Instruction Manual

REQUIRES: Engine: .90 helicopter
          Radio: At least 6-channel with receiver battery
          Gyro: Heading hold
          Main Blades: 690mm or 710mm carbon fiber
          Fuel: Heli blend, 15-30%
          Engine Starter: Electric starter with extended 6mm starting tool
          Tools and field equipment

SPECS:    Fuselage Length: 53.8" (1354mm)
          Fuselage Height: 18.2" (462mm)
          Fuselage Width: 8.7" (221mm)
          Rotor Blades: 27.2-28.3" 690-720mm)
          Main Rotor Diameter: 61.5-63.1" (1563-1603mm)
          Tail Blade: 4.13" (105mm)
          Weight (Fully Equipped): 9.7lb (4400g)
          Main Gear: 111T/114T/115T
          Suggested Rotor Speed: 2000-2100RPM
          Tail Drive: Torque tube
